Lifting 7 Ton Mechanical Reel Elevator With Tensioner For
Transmission Stringing Line
Description:
Our Mechanical Drum Elevators is applicable to be as the support of
large cable reel in laying cables in the city.
It is easy to move
It can be equipped with a braking device, using the foot brake.
We have the complete production equipments and professional
production team to manage the whole process
from producing to packing and shipping.All of the products will be
100% tested before the delivery to ensure the
quality of our products.
Our mechanical Drum Elevators can be used together with Tesmec or
Zeck machines,
please confirm the connection parts before confirm the order.
We have designed and manufactured 4 ton, 7 ton, 3 ton
mechanicalreel elevators for different size of conductor drums.
Quick details:
1. Transmission Line Stringing Equipment Accessories & Tools
2. Hydraulic Drum Elevators
3. Maximum drum size: 1500
4. Rated Load: 70KN
5. Welded Steel with protective coating
6. Drum Hole: 100-120mm
7. Maximum width of drum: 1500-1700mm
8. Galaxy Brand |
Specification:
| Model | Maximum drum size(mm) | Maximum width of drum(mm) | Drum hole(mm) | Capacity(KN) | Brake force(KN) | Rope speed(m/min) | Weight(kg) |
| GLCVI-228 | 1500 | 1100-1300 | 76-103 | 40 | 2 | 80 | 290 |
| GYCVI-229 | 2000 | 1500-1700 | 100-120 | 70 | 2 | 80 | 500 |
| GYCVI-230 | 1500 | ≤1100 | 65-80 | 30 | 2 | 80 | 240 |
Additional Devices:
10 meters soft tube
Disk brake device
Features:
1) easy to carry
2) high quality
3) quick delivery
Application:
Mechanical Cable Drum Stand/Cable Drum Jack is applicable to the
placement of the cable tray
along with hydraulic tensioner.
Maufacturer Introduction:
Galaxy power industry limited was established in 2016, a high-tech
enterprise in China, We are specializing in
R & D, manufacturing and sales of kinds of transmission line stringing equipment and tools such as
hydraulic
puller, tensioner, underground cable conductor pulleys,
anti-twisting galvanized steel rope as well as providing
accessories and technical service for customer. Galaxy has
developed as one of the largest stringing
equipment and tools manufacturer in China which supply more than
200 varieties kinds of goods now.
Production Line:
We have five production lines.
Main configurations of our machine are from Germany and USA
Engine: American Cummins
Main pump: German Rexroth
Main motor: German Rexroth
Speed reducer: German Rexroth
Tail bracket hoisting motor: Amercian Eton
Hydraulic meter: German
Operating handle: German Rexroth
